Wholesale BR1632 3V 120mAh Lithium Button Cell Battery Manufacturer

Short Description:

BR1632 lithium coin cell batteries provide excellent performance and their extensive shelf-life makes them ideal for use in a variety of devices. The BR1632 battery is used for a wide variety of applications such as computer motherboards, watches, calculators, PDAs, electronic organizers, garage door openers, toys, games, door chimes, pet collars, LED lights, sporting goods, pedometers, calorie counters, stopwatches and medical devices.


Product Detail

FAQ

Product Tags

Brand: PKCELL
Model: BR1632
Capacity: 120mAh
Chemical Composition: Lithium
Application: Photovoltaic inverters, servers, medical equipment, military industry
Free promotional accessories: pen, flash light, T-shirt etc.
Oversea Warehouse:Canada,UniteStates,Russian,Australia

Advantages:
1) Environmental friendly,Light weight

2) High density of energy
3) Low self-discharge
4) Low internal resistance
5) No memory effect
6) Free of mercury
7) Safety assurance : No fire, No explosion, No leakage

Disply and storage:
1.Batteries shall be stored in well-ventilateddry and cool conditions

2.Battery cartons should not be piledup in severa layers,or should not exceed a specified height
3.Batteries should not be exposed to direct sun ray for a long time or placed in areas where they get wet by rain.
4.Do not mix unpacked batteries so as to avoid mechanical damage and/or short circuit among each other

Warnings and Cautions:
1.Do not short circuited, recharge, heat, disassemble nor dispose in fire

2.Do not force-discharge.
3.Do not make the anode and the cathode reversed
4.Do not solder directly

Model Discharge Standard  capacity(mAh) (MPQ) Operating Temperature Range(Low) Operating Temperature (High))
BR series–Lithium carbon fluoride battery
BR1225 62KΩ(0.05mA) 45 4800 -40℃ +85℃
BR1632 15KΩ(0.2mA) 120 4000 -40℃  +85℃
BR2032 15KΩ(0.2mA) 200 4000 -40℃ +85℃
BR2325 15KΩ(0.2mA) 170 3200 -40℃ +85℃
BR2330 15KΩ(0.2mA) 240 2000 -40℃ +85℃
BR2335 15KΩ(0.2mA) 280 2000 -40℃ +85℃
BR2450 7.5KΩ(0.4mA) 550 1400 -40℃ +85℃
BR2477 4.7KΩ(0.6mA) 1000 1000 -40℃ +85℃
